3″ SST LIFT KIT – 2022-2024 TOYOTA TUNDRA REAR AIR 2WD/4WD
3” SST Lift Kit Features and Benefits:- 3” Lift allows for up to 35×12.50 tall tires when used on 18″x9″ wide wheels with a +12mm offset- Maintains full operation and range of OEM load-leveling system- Retains factory turning radius- Allows for use of stock 20” wheelsNOTE: Not for use on 2022+ Tundra TRD Pro w/ Bilstein coilover shocks, the TRD rear sway bar option ro trucks equipped with Load-Leveling Rear Height Control Air Suspension. Only work with factory 20″ wheels – will not work with factory 18″ wheels. Most aftermarket wheels are compatible (confirm fitment prior to installation). *****Toyota OEM lift kit cv shafts PT362-3432B and PT362-3431B are recommended by Toyota and required by AutoWheelZone on all lifted 22-UP Tundra’s. Failure to use these axle shafts may lead to damage if used in 4WD not covered by the manufacturer and will not be covered by AutoWheelZone ReadyGuard warranty.*****
About
The all-new 3” SST Lift for the 2022-2024 Tundra is exclusively for Tundra equipped with Load-Leveling Rear Height Control Air Suspension and Adaptive Variable Suspension (AVS). This new kit gives customers that level lift on all four corners of the air-equipped trucks. This new kit is the fast, reliable, and cost-effective way to bring the front of your vehicle level with the rear for that ideal lifted stance. Our front strut spacer eliminates the hassle, time, and concern of compressing springs while our rear airbag spacers allow the user to maintain the full range of use from the rear air system. Shock extensions, brake line spacers and brackets, and a slotted rear ride-height sensor bracket (for fine-tuning adjustments) are included in the kit. 3” SST Lift Kit Features and Benefits:- 3” Lift allows for up to 35×12.50 tall tires when used on 18″x9″ wide wheels with a +12mm offset- Maintains full operation and range of OEM load-leveling system- Retains factory turning radius- Allows for use of stock 20” wheelsNOTE: Not for use on 2022+ Tundra TRD Pro w/ Bilstein coilover shocks, the TRD rear sway bar option. Kits only work with factory 20″ wheels – will not work with factory 18″ wheels. Most aftermarket wheels are compatible (confirm fitment prior to installation). Toyota OEM lift kit cv shafts PT362-3432B and PT362-3431B are recommended by Toyota on all lifted 22-UP Tundra’s. Failure to use these axle shafts may lead to damage if used in 4WD not covered by the manufacturer.
Related products
-
Features and Benefits: – 3″ Front/ 1″ Rear SST Lift Kit – Fits 2020-2024 GM HD 2500/3500- SST lift-specific Forged Torsion Keys – Xtreme-Duty fabricated 4130 chromoly steel upper control arms- Front inner fender bracket to fit larger tires- Allows for no-trim 20×9 0 offset on a 35×12.50 tire. – *Max with trimming: 20×10 -18 offset – 35×12.50. Some fender well trim variances may be experienced between Silverado and Sierra models. – Vehicle-specific performance-tuned Falcon 2.1 monotube dampers on all four corners.Special Note: When setting the torsion key adjustment bolt do not exceed 27” from the wheel center to the fender edge. Exceeding this will overlift the vehicle creating a top-off condition, meaning the suspension has little to no down travel. The result is poor ride quality and premature wear of components.
-
The Rear Track Bar Axle Bracket Kit is for Bronco’s with a 3″ to 4″ lift that corrects vehicle roll center, restores factory handling, and reduces body roll on lifted applications. The billet clamp works in perfect concert with the highly triangulated rear bracket to create the added strength needed under extreme off-road use.
-
4″ COIL SPRING LIFT KIT WITH FALCON SHOCKS AND RADIUS ARMS – 2023-2024 FORD SUPER DUTY F250/F350 4WD
Fits 2023-2024 Ford Super Duty Power Stroke 4WD.4″ Coil Spring Lift Kit with (4) Monotube Falcon 1.1 Shocks.Tubular Radius Arms correct the caster angle included in kit 49-23421.Falcon Dual Steering Stabilizer included in kit 49-23421. Bolt-on lift kit – no structural modifications required.Allows for up to 37″ tall tires on 9″ wide wheels with +18 offset.Diesel trucks with rear single-wheel only.***Trucks equipped with the “Onboard Scale” option will require the Auto-Leveling Headlight Bracket.***PN: 67-23610 – Ford Super Duty Auto-Leveling Headlight Bypass Bracket KitNOTE: Tremor versions will not gain the full 4 inches over stock ride height. Not recommended for 2WD or gas trucks. Single Cab configuration has not been validated for fitment & drivability by AutoWheelZone.
-
– 3″ Front/ 1″ Rear SST Lift Kit – Fits 2020-2024 MY GM HD 2500/3500- SST lift-specific Forged Torsion Keys – Front and rear Falcon 1.1 Monotube series shocks- Xtreme-Duty fabricated 4130 chromoly steel Upper Control Arms- Front inner fender bracket to increase larger tire clearances- Allows for no-trim 20×9 0 offset on a 35×12.50 tire. – *Max with trimming: 20×10 -18 offset – 35×12.50. Some fender well trim variances may be experienced between Silverado and Sierra models. Special Note: When setting the torsion key adjustment bolt do not exceed 27” from the wheel center to the fender edge. Exceeding this will overlift the vehicle creating a top-off condition, meaning the suspension has little to no down travel. The result is poor ride quality and premature wear of components. Max width on stock wheels is 11.5″.
